Profil-Even Level

for straight farrowing crates

1.

06-Profil-25101-600-HT
PROFIL 25101-600-HT
  • 2 wide traction area levels
  • alternating step trays and wide bed bars for vertical foothold

2.

06-Profil-Eben-Trittmulden
step trays
  • at the sides step trays for protected grip of piglets at milk bar
  • more grip, less trouble and less friction

3.

06-Profil-Eben-gerade-Liegebalken_2489
Wide bed bars
  • large bed bars
  • wide, large areas protect against punctual injuries

4.

06-Profil-25100-640
PROFIL 25100-640
  • 60 cm roundly shaped bars
  • teat friendly PROFIL structure
  • 40 cm ling bars for max. manure drainage

Technical Advice

  • length 1000 x width 600 mm, even level
  • PROFIL 25101-600-HT, solid area
    • centred support at 300 mm possible
    • < 5 % opening
  • true-to-size interlocking between cast iron slat and PP-floors
  • step trays and wide bed bars
    • foothold for sows with weak legs on wet and fatty surfaces nearby the trough
  • PROFIL 25100-640
    • 60 cm roundly shaped bars no “squeezing” of teats like at 90° bars
    • 40 cm long bars for max. manure drainage

Products used in this layout

 Ref. No.measure a x b
Cast Iron
Profil25101-600-HT1000x600
Profil even25100-640 40cm long bars1000x600
Polypropylene Flooring
Vario13060-500600x500
Mentor14060-300600x300
Polypropylene Heating Pads
Simplex21012-500-WW-ECO+1200x500
